3-layer panels

3-layer panels are made of full-staves solid wood in thickness 5 mm as top and bottom layer and FJ panel  in thickness 10 or 16 mm as middle layer. All three layers are made of same wood species and are cross glued. Width of staves is fixed, and it’s 70 mm. Thanks to its construction 3-layer panels are much more stable than solid FJ panels or solid panels with full staves. Because of that they are mostly used in futniture industry.

Characteristics:

Assortment:

Quality description:

A side: Strips are graded by colour in order to acchieve homogenic wood appearance. Basically sap wood, brown wood, knots or cracks are not allowed. Technically correct.
B side: Strips are not graded by colour, singular sap wood is allowed, small knots, no surface defects.
C side: “Baumarkt” quality without any colour limitations. Technically correct.

Wood is a natural material. Because of that, single panel should be used only as an example. Deviations in colour and structure in relation to sample are possible.

Colour variations are typical characteristic of wood as natural material and they vary from one wood species to another. Therefore, differences in colour of panels produced in separate production series are possible.

NEW!



NEW MODEL OF 3-LAYER OAK PANELS

TECHNICAL DATA



Thickness: 20/26 mm
Width: 1250 mm – sanded surface
1100 mm – brushed surface
Length: 1250/1650/1900/2050/2300/2500/2750/3000 mm
Width of lamellas: 70-200 mm – RANDOM
Thickness of lamellas: 5 mm
Moisture content: 8-10%
Used glue: D4
Sanding paper grit: 80
GRADING

SURFACES



SANDED



BRUSHED



SMOKED



NEW PRODUCT!



3-LAYER OAK TABLETOP PANELS



TECHNICAL DATA



Thickness: 30/40/50 mm
Width: 900/1000/1100/1200 mm
Length: 1800/2000/2200/2400/2600/3000 mm
Width of lamellas: 70-200 mm
Thickness of lamellas: 5 mm
Moisture content: 8-10%
Used glue: D4
Sanding paper grit: 80

EDGE APPEARANCE

with or without short edge from solid wood elements



PANEL CONSTRUCTION



FRAME
from solid oak wood elements



MIDDLE LAYER
from oak FJ panel



TOP AND BOTTOM LAYER
from oak lamellas



FINISHED PANEL
3-layer oak tabletop panel



GRADING



SURFACES



SANDED



BRUSHED
